A typical boat build timeline in Lombok runs from about 7–10 months for a 15–20 m vessel, 10–14 months for a 20–30 m vessel, and 14–20 months for larger custom projects, depending on specification, survey class and equipment lead times. The proses pembuatan kapal Lombok runs through fixed stages: design, structure, systems, finish, commissioning and sea trial.
Indicative Boat Build Timeline by Size Band
Every hull is different, but planning bandwidth is essential. The table below shows a realistic high-level boat build timeline in Lombok by LOA and complexity, assuming clear decisions, timely payments and normal monsoon conditions.
| Vessel size & type | Typical use | Indicative build duration (months) | Main schedule sensitivities |
|---|---|---|---|
| 15–20 m wooden or GRP | Dayboat, dive boat, simple liveaboard | 7–10 | Design freeze, timber seasoning, simple systems integration |
| 20–25 m wooden / steel / GRP | Island-hopping charter, small cargo, fast shuttle | 9–13 | Monsoon weather, imported engine and generator lead time |
| 25–30 m wooden phinisi or motor vessel | Labuan Bajo liveaboard, multi-day charter | 10–14 | Interior joinery detail, Kemenhub passenger approval, class requirements |
| 30 m+ custom build | Expedition charter, higher passenger count | 14–20 | Complex systems, class survey programme, specialist equipment |
These durations cover keel laying to handover and sea trial in Lombok, assuming the basic commercial framework is already agreed. The commercial process itself is outlined in more detail under the contract, payment and supervision arrangements.
Concept, Design and Lofting
The tahapan bangun kapal Lombok begins with clear definition of use, capacity and operating area. For charter and passenger work, Kemenhub and Syahbandar requirements drive beam, freeboard, compartmentation and lifesaving appliances. For private yachts, owner comfort and crew workflow dominate the early planning.
Concept and basic specification
Initial work normally takes 2–4 weeks and covers:
- LOA, beam, draft, cruising speed and range
- Hull material selection (ulin / other hardwood, steel, GRP, aluminium)
- Propulsion concept: single / twin screw, shaft lines, potential bow thruster
- Cabin count, berths, galley, tankage and cargo / dive deck arrangements
- Target flag, Kemenhub category and any planned class certification
Design development and lofting
Once the basic envelope is set, lines plans and structural scantlings are defined. Traditional wooden hulls may use full-size lofting on the mould floor, while steel or GRP hulls use nested cutting patterns and laminate schedules. This phase typically takes 3–6 weeks and ends with a locked hull form, primary frames and midship section.
Keel Laying, Framing and Primary Structure
Keel laying marks the visible start of the boat build timeline in Lombok. For wooden vessels, seasoned ulin or specified hardwood is brought to the slipway, checked and cut for keel, stem and stern. For steel hulls, pre-cut plate arrives at the yard and is tacked up on the blocks.
Wooden hulls
- Keel and backbone: Keel, stem, sternpost, floor timbers and deadwood are fitted and fastened.
- Frames and ribs: Station frames and intermediate ribs are erected and braced to hold fairness.
- Stringers and beams: Longitudinal stringers and deck beams tie the backbone together.
Backbone and framing usually take 6–10 weeks for a 20–30 m hull, assuming timber moisture content is acceptable and the monsoon does not disrupt deliveries.
Steel or GRP hulls
- Plate and profile cutting: Based on lofted patterns and nesting plans.
- Assembly on jig or blocks: Shell plating is tacked, then welded to approved procedures.
- Bulkheads and floors: Watertight and structural bulkheads installed early for stiffness.
For steel and GRP, hull structure to shell completion on a 20–25 m vessel usually sits in the 8–12 week band.
Planking, Lamination, Deck and Superstructure
The next tahapan bangun kapal Lombok moves from skeleton to closed hull.
Planking and lamination
- Wooden planking: Garboard strakes are set first, then hull planking proceeds up to the sheer, checking fairness and plank seams. Caulking seams are left accessible.
- GRP lamination: Moulds are prepared and gelcoat, skin coats and main laminates laid to the laminate schedule, with core material where specified.
- Steel plating completion: Remaining plates, chine bars and sheerstrakes are installed, welds cleaned and inspected.
Planking or lamination for a 20–30 m hull typically runs 6–10 weeks, subject to weather, material supply and survey inspections where applicable.
Deck and superstructure
- Installation of main deck, bulwarks and cap rails
- Superstructure modules (wheelhouse, cabins, flybridge) fabricated and fixed
- Door and window openings cut and stiffened
Deck and superstructure work often overlaps with late hull work and typically needs 4–8 weeks.
Systems First Fix and Machinery Installation
With hull and main structure defined, the focus moves to systems and machinery. This stage strongly influences how long to build a boat in Lombok, because imported equipment and specialised fittings can hold up progress if not planned.
Machinery and propulsion
- Main engines, gearboxes and shaft lines aligned and chocked
- Shaft log, stern tube, rudder stocks and steering gear installed
- Engine room foundations for generators, compressors and pumps poured or fabricated
Systems first fix
- Fuel, fresh water, grey and black water tanks installed and connected
- Primary piping runs for fuel, bilge, fire and fresh water systems
- Electrical conduits, cable trays and main switchboard positions fixed
- Ventilation ducts and air-conditioning trunk runs placed
On a mid-size 20–25 m vessel, machinery and first fix usually occupy 8–12 weeks, particularly if engines, gearboxes or generators arrive from overseas.
Interior Joinery, Outfitting and Paint
Once the boat is mechanically defined, interior and exterior finishes proceed. This phase is labour-intensive and where the specification has the largest impact on the boat build timeline in Lombok.
Interior joinery and outfitting
- Cabin partitions, doors and furniture modules installed
- Galley units, counters and storage fitted
- Toilet and shower compartments, liners and fittings set
- Flooring, ceiling panels and wall linings completed
- Electrical second fix: lighting, outlets, distribution panels, navigation desk
Exterior outfitting
- Rails, bitts, fairleads and bollards installed
- Deck hardware such as windlass, capstans, hatches and skylights fitted
- Windows, portholes and doors glazed and sealed
Paint and coatings
- Hull fairing, priming and antifouling system applied to specification
- Superstructure and deck coatings, non-slip areas, interior varnish or paint
- Markings for draft, Plimsoll where required, and name / port of registry
Joinery, outfitting and paint for a 20–30 m charter vessel often take 10–16 weeks, depending on interior complexity and weather windows for spraying or open-air coating.
Commissioning, Sea Trial and Handover in Lombok
After structure and finish, the final proses pembuatan kapal Lombok is commissioning, documentation and sea trial.
Commissioning
- Pressure testing of fuel, water and fire lines
- Electrical testing of all circuits, load checks on generators
- Alignment checks, shaft seal and stuffing box verification
- Function tests for steering, autopilot, navigation electronics and communications
- Final interior checks: fixtures, latches, drainage, lighting
Sea trial in Lombok waters
Sea trial Lombok programmes are usually run from Bangsal, Teluk Nara, Senggigi or Lembar, depending on vessel draft and operational plan. Typical trial items include:
- Progressive speed runs and fuel consumption readings
- Crash stop, turning circle and astern tests
- Steering, autopilot and navigation checks in real conditions
- Anchor deployment and retrieval, windlass load test
- Noise, vibration and comfort observations at key speeds
Commissioning and sea trial usually take 3–6 weeks, including punch-list rectification and any inspections required for Surat Ukur, Gross Akte, Pas Besar and, where applicable, class or Kemenhub passenger approval.
Key Schedule Risks for a Lombok Build
Understanding schedule risk is as important as understanding tahapan bangun kapal Lombok. Main influences on duration include:
- Timber seasoning: For wooden hulls, high moisture content in ulin or other hardwoods can force extra air-drying time before planking and joinery.
- Monsoon weather: West monsoon (rough seas, more rain) can affect slipway access, material deliveries and open-air painting opportunities.
- Imported machinery and equipment: Engines, generators, navigation electronics and air-conditioning units can extend lead times if orders are not placed early.
- Design changes mid-build: Layout revisions, extra cabins, or specification upgrades for interiors and systems can push back subsequent stages.
- Regulatory and survey windows: Coordination with Syahbandar, BKI surveyors or other class societies may introduce waiting periods between stages.
For this reason, early and disciplined specification work, as described for any custom boat build in Lombok, is central to keeping the programme inside the initial time band.
What to Send the Build Desk for a Scoped Timeline
To receive a scoped boat build timeline and cost band, send the Lombok Boat Builder Build Desk the following by WhatsApp +628113823875 or email sales@komodoluxury.com:
- Intended vessel size (LOA, beam, approximate draft) and hull material preference
- Planned use (private, charter, dive, passenger transport, cargo) and operating area
- Target cruising speed, engine brand preferences and generator requirements if any
- Cabin count and broad interior standard (simple, mid-range, premium finish)
- Any regulatory framework or class target (flag, Kemenhub passenger count, class society)
- Existing drawings or reference vessels, if you have them
With this information, the Lombok Boat Builder Build Desk can return an indicative schedule by stage, identify the main timing risks for your project, and outline the next steps toward contract and pre-production planning.
Frequently Asked Questions
How long does a boat take to build in Lombok?
Ranges, honestly: an open dive or day boat typically runs a few months; a Gili passenger fast boat longer once engines and certification are counted; a 20 m wooden hull spans seasons. The variance drivers are engine lead times, finish level, certification scope and the monsoon calendar — a single confident number would be fiction.
Can I visit the yard during the build?
Yes, and the desk schedules visits at approval gates where owner presence adds the most: lofting, before planking or lamination closes the structure, and sea trial. Between visits, every gate still produces evidence-standard photo reports and video, so nothing depends on being there.
What happens at a sea trial?
Loaded runs at service and full load, manoeuvring, instrumented engine readings, and a systems shakedown — followed by a written defect list. What must clear before the final payment releases is defined in advance, and independent verification at this gate is covered by the survey and inspection programme.
Does the rainy season stop building?
It reshapes the schedule rather than stopping it: lamination, fairing, painting and launch windows move to suit humidity and sea state, while framing and joinery continue under cover. A Lombok build plan that ignores the monsoon calendar is a delay claim waiting to be written.
